Portable Hydraulic Rebar Bender

Portable Hydraulic Rebar Bender

Portable Hydraulic Rebar Bender is designed for bending steel bars in high-rise buildings, highways, railway foundation pile cages, and various building frameworks. It is ideal for on-site bending of pile foundation and pile head steel bars. Driven by a hydraulic system, this compact and lightweight machine is easy to operate, allowing one person to complete bending tasks efficiently. Unlike traditional manual bending and welding, this method enhances accuracy, reduces labor intensity, improves safety, and boosts work efficiency.

Product Features

Simple Structure and Easy Operation

• Ensures excellent stability and high reliability

• Improves steel bar bending quality and overall work efficiency

Versatility on Construction Sites

• Perfect for areas that are difficult to access with traditional bending machines

• Especially useful after steel bars are tied in place

High Hydraulic Power

• Powered by an advanced hydraulic system

• Provides high bending force, capable of bending up to 40mm steel bars

Dual Functionality

• No need to switch the working head

• Supports both bending and straightening functions at fast speeds

Ease of Use and Safety

• User-friendly design reduces physical strain

• Compact, mobile, and safe for on-site operations

How to Use the Portable Rebar Bender

Main Components

• Bending and straightening head

• Oil pipe

• Electric hydraulic pump

Preparation

1. Check that the oil pipe and oil meter are functioning properly

2. Connect the quick coupling on the oil pipe to the coupling on the bending head

3. Position the steel bar flat and aligned with the bending module

Operation

1. Switch on the machine to start the oil pump

2. As the load increases, hydraulic pressure rises to 63Mpa

3. The push shaft extends and bends the steel bar to the preset angle

Adjustments and Completion

• Manually verify the bending angle

• To release pressure, turn the manual valve handle

• After use, power off the machine and disconnect the quick coupling
